DC 12V LED Drivers
- SKU:
- ACDCDR
- MPN:
- LED-DRJ
- Availability:
- Ships in 3-5 business days
3 options
Frequently bought together:
Description
Used with our Low Votlage LED Lightstar String Lights, this driver series features two options with universal 100-277V AC power input and another designed to operate with any standard ELV, MLV, & Incandescent TRIAC (Leading edge) dimmer switch. Both have exceptional reliability and Class 2 rating. Standard built-in protections include short circuit, over-load, and over-temperature protections. See complete features and specifications below.
60-Watt, Non-Dimmable Driver Features:
- 12V DC constant voltage hardwire driver
- Non-dimmable option for installations where primary side dimming is not needed
- Short circuit, over-load, and over-temperature protections
- Slim, compact aluminum housing design (7.4"L x 3.76"W x 1.72"H)
- Integrated wiring compartment
- Free air convection cooling
- Class 2, Class P, Type HL, FCC compliant
- cULus Listed, Wet location rated
- Input Voltage: 100-277V AC
- Output Voltage: 12V DC / 24V DC
- Max Load: 60W
- Minimum Load: 6W
- Operating Temperature: -40°F to 140°F (-40°C to 60°C)
- 60-watt, Non-Dimmable Specification Sheet
100-Watt, Non-Dimmable Driver Features:
- 12V DC constant voltage hardwire driver
- Non-dimmable option for installations where primary side dimming is not needed
- Short circuit, over-load, and over-temperature protections
- Slim, compact aluminum housing design (8.66"L x 3.76"W x 1.72"H)
- Integrated wiring compartment
- Free air convection cooling
- Class 2, Class P, Type HL, FCC compliant
- cULus Listed, Wet location rated
- Input Voltage: 100-277V AC
- Output Voltage: 12V DC
- Max Load: 100W
- Minimum Load: 10W
- Operating Temperature: -40°F to 140°F (-40°C to 60°C)
- 100-watt, Non-Dimmable Specification Sheet
60-Watt, Dimmable Driver Features:
- 12V DC voltage 60W hardwire LED driver
- Dimmable with ELV, MLV, & Incandescent TRIAC dimmers
- Features integrated wiring compartments for line and low voltage
- Forward phase & reverse phase compatible
- Short circuit, over-load, and over temperature protections
- Slim compact housing design - Less than 1-1/16" in height
- Class II / cULus Listed - Wet location rated
- 60-watt, Dimmable Specification Sheet
